Product Introduction
>Product Introduction
High tension insulator are a special type of insulation control that can play an important role in overhead transmission lines. In the early years, insulators were mostly used for utility poles, but gradually developed to include many disc-shaped in sulators hung at one end of high voltage power line connection towers to increase the creepage distance. They are usually made of glass or ceramic and are called insulators. Insulators should not fail due to various mechanical and electrical stresses caused by changes in environmental and electrical load conditions, otherwise insulators will not have a significant effect and will damage the use and operating life of the entire line.
High voltage power composite insulator is a type of insulator product, which refers to insulators used for high-voltage and ultra-high voltage overhead transmission lines and substations. In order to meet the needs of different voltage levels, different quantities of single insulators of the same type are usually used to form insulator strings or multiple insulation pillars. The product consists of iron caps, tempered glass pieces, and steel feet, which are bonded together with cement adhesive.
This product is a part of porcelain insulator, be used to connect and protect the porcelain insulator. This casting steel cap raw material can used Ductile iron or other kind alloy steel, product can do heat-treatment, and finished with Hot Dip Galvanizing, that will improve this product quality and life !
1. Products including: insulator iron cap /clevis cap /socket cap /rod end cap /post end cap;
>Product Advantage
Relatively stable quality
NGZR have more than 10 years experience of R&D / Manufacutring / After-sales srevice for High Mangese & High Chromium alloy casting wear parts for Mining and Ductile iron castings for Electric motor shell and Water Pump sheel.
Lower usage cost
NGZR have large production capacity with Advanced Lost foam process full Automatic precision casting line and Resin-sand Wooden mould manual casting production line, we can provide more competive price products to all customers. So customer will get lower production unit cost than before.
Customized alloy Steel composition
NGZR foundry was able to match customer needs to readjust the Chemical Composition of alloy steel content (Mn /Cr) , or increased other special metallic element (Si /Mo /Cu /Ni etc), through special heat-treatment processing, can help this casting Excavator bucket wear-parts have special Mechanical performance, to follow different customer’s different working conditions.
Customized drawing size and shape
NGZR foundry can follow customer’s drawing of exist steel cap to customized . Also we can revised the exist steel cap shape / thickness to help customer get lower purchase cost.
Door to door measure & Installation Guide
If customer can’t provide drawing of existing steel cap , NGZR will arrange our service engineer come to measuring and design of the one-stop service with free of charge.
If customer required, NGZR provide door to door installation guide serivce with pay charge.
Technical Parameters
>Technical Parameters
| #1 Alloy Chemical Composition: | |||||||||
ITEM | C | Si | Mn | P | S | Cr | Mo | Ni | Cu |
Mn13Cr2 | 1.05-1.35 | 0.3-0.9 | 11-14 | ≤0.06 | ≤0.04 | 1.5-2.5 | -- | -- | -- |
Mn13Cr2Mo | 1.05-1.35 | 0.3-0.9 | 11-14 | ≤0.06 | ≤0.04 | 0.4-1.2 | 0.4-1.2 | -- | -- |
Mn18Cr2 | 1.05-1.35 | 0.3-0.9 | 16-19 | ≤0.06 | ≤0.04 | 1.5-2.5 | -- | -- | -- |
Mn22Cr2 | 1.05-1.35 | 0.3-0.9 | 20-22 | ≤0.06 | ≤0.04 | 1.5-2.5 | -- | -- | -- |
Cr26Ni5 | ≤0.20 | ≤0.20 | ≤0.20 | ≤0.06 | ≤0.04 | 24-28 | ≤0.50 | 4-6 | -- |
Cr26Ni12 | 0.2-0.5 | ≤0.20 | ≤0.20 | ≤0.06 | ≤0.04 | 24-28 | ≤0.50 | 11-14 | -- |
Cr25Ni20Mo | 0.35-0.45 | ≤0.20 | ≤0.20 | ≤0.06 | ≤0.04 | 23-27 | 1.1-1.4 | 19-22 | -- |
Cr15Mo2 | 2-2.8 | ≤0.10 | 0.5-1.0 | ≤0.10 | ≤0.06 | 13-18 | 1.5-2.5 | 0-1.0 | 0-1.2 |
Cr20Mo2Cu | 2-3.0 | ≤0.10 | 0.5-1.0 | ≤0.10 | ≤0.06 | 18-22 | 1.5-2.5 | 0-1.0 | 0.8-1.2 |
Cr26Mn | 2-3.0 | ≤0.10 | 0.5-1.0 | ≤0.10 | ≤0.06 | 23-28 | 0-1.5 | 0-2.0 | 0.8-1.2 |
Remark: we can make any other type of alloy materials for customized. | |||||||||
| #2 Product Physical Technical: | |||||
ITEM | Yield strength Yp0.2 / MPa | Tensile Strength Rm / MPa | Impact absorption KU2 /J | Hardness HBW | Micro -structure |
Mn13Cr2 | ≥ 390 | ≥ 735 | ≥ 96 | ≤ 300 | A + C |
Mn13Cr2Mo | ≥ 390 | ≥ 735 | ≥ 96 | ≤ 300 | A + C |
Mn13Cr2Ni3 | ≥ 370 | ≥ 705 | ≥ 118 | ≤ 300 | A + C |
Mn18Cr2 | ≥ 390 | ≥ 735 | ≥ 96 | ≤ 300 | A + C |
Cr26Ni5 | ɑ ɓ(MPa) 590 | A + F | |||
Cr26Ni12 | ɑ ɓ(MPa) 490 | A + F | |||
Cr25Ni20Mo | ɑ ɓ(MPa) 490 | A + F | |||
Cr15Mo2 | HRC ≥ 53 | M+ A + C | |||
Cr20Mo2Cu | HRC ≥ 58 | M+ A + C | |||
Cr26Mn | HRC ≥ 55 | M+ A + C | |||
M= Martensite ; C= Carbide ; A= Austenitic ; F= Ferritic ; | |||||
Remark: we can make any other special mechanical properties for customized | |||||
Product Uses
>Product Application
Widely used in Extra-high & Ultra-high& high & low voltage power transmission line
>Product design & uses
#1 More than 15 years experience for professional manufacture wear-resistant casting spare parts of mill & Crusher machinery & Excavating machinery.
#2 Custom-made design,
#3 Products have high abrasion resistance.
#4 Products have long service duration.
#5 Products are easy and fast installation and replacement;
#6 OEM and ODM are available.
